Bike Capacity:
Standard: 2 bikes
Expandable: Up to 4 standard bikes (with extra parts)
E-Bikes: Up to 2 (due to weight limits)
Max Load: 60 kg
Adjustable Height: Telescopic structure, 80–150 cm vertical wheelbase for flexible installation.
Stability: Adjustable upper structure and rounded tube design for better stability.
Bottom Support Bar: Included for secure fixing.
Supplied With:
1 x Bike-Block Pro 1 (locking system)
1 x Bike-Block Pro 3 (locking system)
Security Strip
2 x Rail Plus (bike rails)
Brackets
Technical Specs:
Vertical Wheelbase: 80–150 cm (adjustable)
Horizontal Wheelbase: 60 cm (distance between brackets)
Distance Between Rails: 15 cm
Dimensions: 128 x 69 x 80 cm (standard open position, minimum vertical wheelbase)
Expandability:
To carry up to 4 bikes, add:
Bike-Block Pro 2 and 4
Two additional Rail Plus rails
- Telescopic rail support base
- Aluminium, light weight and oval section, increased safety
- Rail Plus
- New design for increased torsion and flexural strength
- Tubes
- Aluminium 6060, oval section
- Bike-Block
- To securely lock the bike
- Installation
- On the rear wall
- Vehicle type - Motorhomes
- Weight - 10.2kg
- Max load - 60kg
- Colour - Aluminium
Technical Information
SKU: 02096-09-
Barcode: 8004815437145
Brand: Fiamma
